TELESCOPIC BOOM LIFTS
Telescopic Boom Lifts

460SJ

Dimensional Data
Ground Clearance 1 ft / 0.3 m
Machine Height 8 ft 1 in. / 2.47 m
Machine Length 29 ft 3 in. / 8.91 m
Machine Width 7 ft 7 in. / 2.31 m
Platform Dimension A 3 ft / 0.91 m
Platform Dimension B 8 ft / 2.44 m
Platform Height 46 ft / 14.02 m
Tail Swing 2 ft 10 in. / 0.86 m
Tire Size 12 x 16.5  Pneumatic Lug Tread Tires


Reach Specifications
Horizontal Jib Rotation 0 Degrees
Horizontal Outreach 39 ft / 11 m
Platform Height 46 ft / 14.02 m
600S
Dimensional Data
Ground Clearance 1 ft / 0.3 m
Machine Height 8 ft 5 in. / 2.56 m
Machine Length 28 ft 5 in. / 8.65 m
Machine Width 8 ft 2 in. / 2.49 m
Platform Dimension A 3 ft / 0.91 m
Platform Dimension B 8 ft / 2.44 m
Platform Height 60 ft 3 in. / 18.36 m
Tail Swing 3 ft 9 in. / 1.14 m
Tire Size 39 x 15 - 22.5  Lug Tread


Reach Specifications
Horizontal Jib Rotation 0 Degrees
Horizontal Outreach 49 ft  6 in. / 15.09 m
Platform Height 60 ft 3 in. / 18.36 m
660SJ
Dimensional Data
Ground Clearance 1 ft / 0.3 m
Machine Height 8 ft 5 in. / 2.56 m
Machine Length 28 ft 5 in. / 8.65 m
Machine Width 8 ft 2 in. / 2.49 m
Platform Dimension A 3 ft / 0.91 m
Platform Dimension B 8 ft / 2.44 m
Platform Height 66 ft 8 in. / 20.32 m
Tail Swing 3 ft 9 in. / 1.14 m
Tire Size 39 x 15 - 22.5  Lug Tread


Reach Specifications
Horizontal Jib Rotation 0 Degrees
Horizontal Outreach 56ft  9 in. / 17.3 m
Platform Height 66 ft 8 in. / 20.32 m
860SJ
Dimensional Data
Ground Clearance 1 ft / 0.3 m
Machine Height 10 ft / 3.05 m
Machine Length 40 ft / 12.19 m
Machine Width 8 ft 2 in. / 2.49 m
Platform Dimension A 3 ft / 0.91 m
Platform Dimension B 8 ft / 2.44 m
Platform Height 86 ft / 26.21 m
Tail Swing 4 ft 8 in. / 1.42 m
Tire Size 315 - 625  Pneumatic


Reach Specifications
Horizontal Jib Rotation 0 Degrees
Horizontal Outreach 75 ft / 22.86 m
Platform Height 86 ft / 26.21 m
E600J
Dimensional Data
Ground Clearance 1 ft / 0.3 m
Machine Height 8 ft  4 in. / 2.54 m
Machine Length 30 ft 9 in. / 9.37 m
Machine Width 7 ft 11 in. / 2.41 m
Platform Dimension A 2 ft 6 in. / 0.76 m
Platform Dimension B 6 ft / 1.83 m
Platform Height 60 ft 3 in. / 18.36  m
Tail Swing 4 ft  / 1.22 m
Tire Size 36 * 14 - 22.5 Non-marketing Pneumatic
Wheelbase 9 ft / 2.74 m


Reach Specifications
Horizontal Jib Rotation 0 Degrees
Horizontal Outreach 75 ft / 22.86 m
Platform Height 86 ft / 26.21 m
S-45
Working Height 51 ft (15.72 m)
Platform Height 45 ft (13.72 m)
Horizontal Reach 36 ft 8 in. (11.18 m)
Lift Capacity 500 lbs. (227 kg)
S-65
Working Height 71 ft (21.80 m)
Platform Height 65 ft (19.80 m)
Horizontal Reach 56 ft 2 in. (17.10 m)
Lift Capacity 500 lbs. (227 kg)
S-85
Working Height 91 ft (21.80 m)
Platform Height 85 ft (25.90 m)
Horizontal Reach 76 ft 6 in. (23.30 m)
Lift Capacity 500 lbs. (227 kg)
Contact us to rent your telescopic boom lifts.
